FRAMESET
FRAME
ROGUE 29" 6061 Aluminium FRAME
MODERN GEOMETRY / MACHINE FORMED TUBING / STANDARD 135mm QR 9mm REAR AXLE / DISC ONLY

SIZE
15-17-19-21-23

SUSPENSION
FORK
TRC 595 29" COIL 100mm
29″ / 100mm / COIL SPRING / 30mm STANCHIONS / MAGNESIUM LOWER LEG 9mm QR / HYDRAULIC LOCKOUT

FORK FENDER
N/A

REAR SHOCK
N/A
N/A

DRIVETRAIN
CHAINWHEEL
PROWHEEL 1 X 8 32T
PROWHEEL / 32T / 8 SPEED / ALLOY CRANK / STEEL CHAINRING / NO GUARD / S – 170mm CRANKARM / M L XL – 175mm CRANKARM

DERAILLEUR FRONT
NIL

DERAILLEUR REAR
MICROSHIFT RD-M5185M ACOLYTE

SHIFTER LEFT
NIL

SHIFTER RIGHT
MICROSHIFT SL-M7180-R

CHAIN
KMC Z7

FREEWHEEL
MICROSHIFT CS-H083 12-46T

BB SET
CH-52, One Piece, BC1.37”×24T, One piece

SPEED
1 x 8 SPEED

BRAKES
BRAKE LEVER
PROMAX SOLVE-ST

BRAKE FRONT
PROMAX SOLVE-ST DSK-925 WITH 180mm ROTOR

BRAKE REAR
PROMAX SOLVE-ST DSK-925 WITH 160mm ROTOR

BRAKE CABLE
BLACK

WHEELS
RIMS
TR COMP RIM 28H
TR MD16 AL6061 36H 29″ MATT BLACK

HUB FRONT
ALLOY Q/R DISC BLACK
DC-1420, 14Gx28H, Q/R-M9x100x108mm

HUB REAR
ALLOY Q/R DISC BLACK
14G DC-1425, 8/9/10s, 14Gx28H, Q/R-M10x135x145mm

SPOKES
STEEL, ED BLACK 14Gx290mm / 14Gx288mm

TUBE
29″ A/V

TYRES
VITTORIA BARZO 29" X 2.25
XC / 1C COMPOUND / 26TPI NYLON RIGID BLACK WALL

COMPONENTS
GRIP
TR STD MTB GRIP

HANDLEBAR
TR COMP FLAT H/BAR 750mm
TR HB-M003 FLAT 750mm

HANDLEBAR STEM
TR COMP H/BAR STEM
TR SM-001 ALLOY OVERSIZED XS/S = 60mm / M/L = 80mm / XL = 100mm

HEADSET
FP-871, Ball retainer, Semi, ￠28.6×￠44×￠52mm

SPACER
10mm X 2 PCS

SADDLE
YBT-K245F041

SEAT POST
TR COMP 31.6mm
TR SP-003D RIGID ALLOY 31.6mm 350mm

SEAT CLAMP
PROMAX 327 Q

PEDAL
PP BODY/STEEL CAGE

WEIGHT
BIKE WEIGHT
14.3 kg
